Fireproof wall

Magnesium Oxide Boards are a man made factory-produced non-insulating sheathing board products that are used for general construction applications. MgO board is similar to traditional drywall or cement board, but is much stronger, fireproof, and has a higher resistance to mould, mildew, moisture, and weather. The MgO board is becoming popular all over the world to use for walls, such as SIP, partition wall, exterior wall, decorative wall, and modular houses.

Category：

Fireproof walls

产品附件：

info@zcmgo.com

Quote

Standard Solutions

Application
Application	Type	Formula	Thickness	Density	Fiberglass mesh
SIP-Interior	Non-woven mgo board	Chloride content≦0.1%	10~15 mm	950~1000 kgs/m³	2 layers
SIP-Exterior	Non-woven mgo board	Chloride content≦0.1%	15mm	1100~1200 kgs/m³	4 layers
SIP-Exterior	Sanded mgo board	Chloride content≦0.1%	12mm	1100~1200 kgs/m³	4 layers
Modular house Container house Prefabricated house	Non-woven mgo board	Chloride content≦0.1%	4~12mm	950~1000 kgs/m³	2 layers
Partition wall	Non-woven mgo board	Chloride content≦0.1%	6~12mm	950~1000 kgs/m³	2 layers
Exterior wall	Non-woven mgo board	Chloride content≦0.1%	15~20mm	1100~1200 kgs/m³	4 layers
Exterior wall	Sanded mgo board	Chloride content≦0.1%	12~20mm	1100~1200 kgs/m³	4 layers

SIP

A SIP is a Structural Insulated Panel. They consist of a rigid foam core sandwiched between 2 structural sheathings. The most common sheathing used around the world are OSB and Magnesium Oxide (MgO).
MgO board has gradually replaced OSB as the SIP panel due to its superior performance, as well as environmental protection, health, low carbon and other advantages.

Modular house

Interior walls usually use MgO boards with thicknesses ranging from 6 to 10 mm, while exterior walls may require thicker boards, such as 10 to 15 mm, to provide enhanced insulation.

Partition wall

Interior walls and partition walls are suggested non-woven boards, thicknesses of 6 to 12 millimeters, as the use environment is relatively stable, the requirements for the board do not need to be too high

Exterior wall

Exterior wall suggested 12-15 mm, or thicker, according the the environmental, such as the temperature, humidity, extreme weather, etc.
We customize the formula for customers according to the different environment, to ensure the service life of the board.
The critical for mgo board to be used for exterior wall is to be waterproof.

无

Other solutions

Fireproof wall

→

SIP

Partition wall

Exterior wall

Modular house

Flooring

→

Flooring is one of the most widely used applications of mgo board. The advantages of mgo board in terms of strength, flexibility, fireproof, moisture resistance, termite resistance, health safe, insulation and a very low carbon footprint of only 5% make it quickly become an excellent substitute for traditional real estate materials. The application of mgo board in flooring can be subdivided into the following three types.

MgO Subflooring

MgO Underlayment

MgO container flooring

Fireproof doors

→

Every year, countless lives are lost worldwide due to fires. Therefore, many countries worldwide are continually raising the standard of fire safety in buildings. The magnesium oxide boards are now widely utilized in fire doors and are favored for their A1-level fire resistance.

Non-woven mgo boards
